HDZero Goggles 2

HDZero Goggle 2 – Next-Level FPV Goggles

The HDZero Goggle 2 builds on the success of the original with practical upgrades pilots will immediately appreciate. Featuring a sharper, dust-resistant optical module, built-in analog receiver, integrated WiFi mirroring, and a protective hard case.

It keeps everything that made the original great—ultra-low latency, open-source flexibility, and full digital + analog support—while adding more value and convenience for everyday flying.

Why Choose the HDZero Goggle 2?

• 🔓 Open-source software & CAD files – fully customizable
• ⚡ Ultra-low latency (as low as 3ms glass-to-glass)
• 🖥️ Crystal-clear digital video with no warping or color shifting
• 👁️ 1080p 90Hz OLED micro-displays
• 🎯 Multiple resolutions: 1080p30, 720p60, 540p90, 540p60
• 🤝 Fly with friends without interference (1-way broadcast)
• 📡 Improved analog reception with real-time deinterlacing
• 🔄 One goggle for digital, analog, and HDMI

Key Features

🔍 Optics & Display

• Fully enclosed optical module to keep dust out
• Sharper edges with <1.5% distortion
• 90Hz 1080p OLED micro-displays
• Adjustable IPD (58–72mm)
• Focus adjustment (+4 to -7 diopter)
• Supports diopter lens inserts

📡 Connectivity

• HDMI input & output
• 3.5mm analog AV input
• Headphone/microphone combo jack
• Built-in WiFi for streaming & mirroring
• Built-in ELRS backpack support

🎮 Performance

• 3ms glass-to-glass latency with no jitter or dropped frames
• Enhanced analog signal handling
• Built-in H.265 DVR (HDMI / Analog / HDZero)
• 6-axis head tracking (pan + tilt)

🧊 Cooling & Design

• Three independently controlled cooling fans
• Rail mounting system for antennas/accessories
• Recessed SMA connectors (no need to remove antennas)
• On/off sliding switch (easy to confirm by sight or feel)

Specifications

• Resolution: 1920×1080 @ 90Hz (OLED)
• FOV: 46°
• HDZero latency: <3ms
• Analog latency: <2ms
• HDMI latency: <1ms
• IPD range: 58–72mm
• Diopter range: +4 to -7
• Input voltage: 7V–25.2V (2S–6S)

What’s Included

• 1× HDZero Goggle 2
• 1× Wide face plate
• 1× Narrow face plate
• 1× Foam padding
• 1× Goggle strap
• 1× XT60 cable (1200mm)
• 1× HDZero VTX programming cable
• 1× Hard case travel box
• 1× Lens cloth

Why the HDZero Goggle 2 Costs More — And Why It’s Worth It

The HDZero Goggle 2 introduces meaningful upgrades that improve performance, durability, and convenience:

✨ What’s New:

• Improved Optical Module
• Sharper image and dust-resistant design
• Built-in High-Sensitivity Analog Receiver
• No need for additional $50–$150 modules
• Integrated WiFi Mirroring
• Stream your FPV feed directly to phone or PC
• Included Hard Case
• Added protection during transport and storage
